Neutralization and Purification Environmental Protection Equipment for Industrial Exhaust Gas

Equipment Description

I. Workflow

Exhaust Gas Capture: A gas hood covers the pollution source and draws the exhaust gas into the treatment system through negative pressure suction.
Primary Filtration: A dry filter intercepts dust and large particles.
Neutralization and Purification: Acidic exhaust gas enters the spray tower and reacts with alkaline solution to produce a salt solution that is recycled.
Deep Adsorption: Organic waste gas/cyanide is degraded through activated carbon adsorption and discharged through the chimney after meeting standards.

II. Technical Parameters

Parameters	Specifications
Airflow	1000-100,000 m³/h (customizable)
Applicable Exhaust Gas Type	Acid mist (sulfuric acid, nitric acid, hydrofluoric acid), cyanide, VOCs, chromic acid mist
Temperature Range	≤80°C (high-temperature exhaust gas requires pre-cooling)
Emission Standards	Complies with the "Comprehensive Emission Standard for Air Pollutants" (GB16297-1996)

III. Equipment Advantages

High-Efficiency Purification: Multi-stage cascade treatment achieves a comprehensive purification rate of ≥90%, suitable for complex exhaust gas compositions
Corrosion-Resistant Design: Fiberglass, stainless steel, and hydrofluoric acid-resistant coating extend equipment life
Low-Energy Operation: A circulating spray system reduces reagent consumption, and automated control reduces labor costs
Modular Expansion: Flexible configuration of spray towers, adsorption towers, and other units adapts to production line upgrades

IV. Operation and Maintenance Key Points

Daily Maintenance: Monitor the pH value of the spray liquid (recommended 8-10), and replenish NaOH solution every shift
Clean dust from the filter monthly, and replace the activated carbon and packing layer every six months
Troubleshooting: Abnormal fan vibration: Check the impeller for corrosion or dust accumulation, and calibrate the dynamic balance
Decreased purification efficiency: Check the spray liquid concentration, activated carbon saturation, and nozzle blockage

V. Application Scenarios

Acidic Waste Gases: Acid mist (sulfuric acid, hydrofluoric acid) from electroplating tanks
Organic Waste Gases: Cyanide and VOCs emitted from stripping and cleaning processes
Dust Control: Metal dust (chromium, nickel) from polishing and grinding processes

Main Structures and Components

I. Core Structural Modules

Exhaust Gas Collection System
- Gas Hood: Made of stainless steel, fiberglass, or corrosion-resistant PP, it covers pollution sources such as electroplating tanks and pickling tanks
- Exhaust Duct: Made of fiberglass or PVC, with a diameter of 150-500 mm, the layout minimizes bends to reduce air resistance
Pretreatment Unit
- Dry Filter: A metal filter (pore size ≤ 2 mm) intercepts large dust particles and liquid droplets
- Wet Scrubber (Optional): Initially neutralizes acidic exhaust gases using a water curtain or spray

II. Multi-Stage Purification Devices

Acid and Alkali Waste Gas Treatment Unit
- Spray Tower: Tower Material: 316L stainless steel or fiberglass reinforced plastic (FRP)
- Padding: PP Pall rings/Raschig rings increase the gas-liquid contact area
- Mist Eliminator: Wire mesh or baffle structure removes entrained droplets
Organic Waste Gas/Heavy Metal Treatment Unit
- Activated Carbon Adsorption Tower: Honeycomb activated carbon absorbs cyanide, VOCs, and chromic acid mist
- Catalytic Combustion Unit (RCO): Decomposes high-concentration organic waste gas at high temperatures

III. Power and Auxiliary Systems

Corrosion-Resistant Fan: Made of fiberglass or polypropylene, with air volume of 1000-100,000 m³/h
Circulating Fluid System: The spray tower is equipped with an alkaline solution circulation pump
The wastewater is separated from salts in a sedimentation tank before being discharged or reused

IV. Control and Emission Systems

Automated Control Cabinet: Integrated pH sensor and air pressure monitoring module
Chimney Exhaust Outlet: Height ≥ 15 m, accelerating exhaust gas diffusion and dilution

V. Differentiated Components (Expanded by Scenario)

Explosion-proof Design: When handling flammable cyanide waste gas, the fan and piping must be grounded
Hydrofluoric Acid Resistant Coating: To protect against hydrofluoric acid mist, the spray tower's interior is coated

Features

High cost performance: Achieves the best cost performance based on economic affordability
Advanced design: Showcases the image of a modern and advanced enterprise
High adaptability: Meets current production requirements with room for future development
Quality compliance: Strictly adheres to the ISO900 quality management system
